QuicRun WP 860 Dual Brushed - 30105400 - HOBBYWING  [HW-30105400]

Effortless Operation

This ESC is extremely designed for fresh novices and intermediate modelers;
it not merely holds ahead the outstanding quality of HOBBYWING products
but simplifies the procedure.

Applicable to all or any or any or any or any Weather Conditions

The waterproof and dust-proof design permits the QUICRUN WP-860-Dual-Brushed
become present in many climate with no problem of harm triggered
on ESC from water or dirt.

Built-in BEC

The integrated switch mode BEC with a maximum manufacturing of 6Amp and voltage of 5V
appreciate this to ESC appropriate for different servos.

A simple task to Use

This ESC features car throttle calibration and parameter environment
via jump caps is easy-to-use, particularly highly relevant to unique novices.

Double Output

This ESC can drive two brushed machines too.
It’s economical and relevant to low-speed crawlers and tanks which operate two machines

Item Specification

Type

• Scale : 1/8^th、1/10^th
• Brushed/Brushless : Brushed
• Sensored/Sensorless : -
• Waterproof : WP

Specifications

• Cont./Peak Present : 60A/360A
• Input : 2-4S LiPo/6-12 Cells NiMH
• BEC production : change Mode:5V/3A

Wires & Connectors

• Input cables : Red-16AWG-150mm*2/Black-16AWG-150mm*1
• Output cables : B lue-16AWG-100mm*2/Yellow-16AWG-100mm*2
• Input Connectors : No
• Output Connecotors : 4.0 Bullet Connectors (Female)

Fan

• Size : 25.0x25.0x10.0mm
• Voltage Amount : 5-7.4V
• Powered by : operating on BEC

ESC Programing via

• SET Button on ESC : perhaps not Supported
• LED Program Box : maybe not Supported
• LCD Program Box : not Supported
• WiFi Module : maybe not Supported
• Program Port : Dip Switch

Firmware

• Firmware Upgrade : not Supported

Size & Weight

• Size : 46.0x36.0x26.3mm
• Weight : 73g

Applications

• Motors : Brushed Motors
• Vehicles : 1/8^th, 1/10^th Touring Cars/Buggies/Trucks//Rock Crawlers
• KV Rating/T Count : 2S LiPo: T≥12T
  3S LiPo: T≥18T
  4S LiPo: T≥24T
  (540/550/775 Size machines)
