Seaking 30A V3 - 30302060 - HOBBYWING  [HW-30302060]

Effectiveness & Reliability

Built with top-notch elements plus along with cutting-edge firmware,
the Seaking 60A V3.1 is showcased by unmatched performance and reliability.
numerous safety adjustable alternatives might present in use,
with the use of the low-voltage cutoff protection,
thermal security and throttle indicator loss security.

Effective Cooling System

The Hobbywing patented heat-conductive copper club target concerning the energy board of
the Seaking 60A V3.1 can effectively and effectively go temperature towards incorporated CNC machined
billet aluminum water cooled temperature sink housing hence keeping
your ESC as cool as you possibly can.

Waterproof Design

100percent waterproof with no need of extra security.

Integrated BEC

The integrated switch mode BEC with an optimum production of 6Amp and
voltage of 6V understand why ESC appropriate high voltage servo.

Original Algorithm Design

The unique algorithm implemented in ESC end up in the acceleration
more amazing and cruising more stable.

Individual PRG/FAN Port

The split PRG/FAN slot about the ESC can connect ESC to an exercise program
industry (via the trio-color development cable) and commence ESC development.

Type

• Brushed/Brushless : BL
• Waterproof : WP

Specifications

• Cont./Peak Present : 30A/180A
• BEC production : Linear Mode:6V/1A

Wires & Connectors

• Output cables : Black-16AWG-75mm*3
• Input Connectors : No
• Output Connecotors : No
• Transmitter : Supported
• LED Program Box : Supported
• LCD Program Box : not Supported
• WiFi Module : maybe not Supported
• Program Port : Program/Throttle Wire

Firmware

• Firmware Upgrade : maybe not Supported

Size & Weight

• Size : 54.5x28.3x18.7mm
• I.D./O.D. of fluid Cooling Pipe : Ф2.0/4.0 mm
• Weight : 41g

Applications

• Boat Length <45cm
