Hobbywing 30401053 4300KV Sensored Motor for 1/10 Scale [HW-30401053]

HOBBYWING XERUN-3652SD-4300KV-D3.175-G2 - 30401053

Price:

NZD$0.00

Brand:

Hobbywing

Model:

HW-30401053

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the

R/C Models - Motor / ESC / Cooling Fan - Motor - Car Motors

Precision throttle control from Hobbywing

The Hobbywing XERUN-3652SD-4300KV-D3.175-G2 motor is engineered to provide refined power delivery for 1/10 scale RC rigs. Its sensored brushless setup ensures smooth acceleration and predictable control for focused drivers.

Why racers pick this motor

Sensored Design: Smooth commutation for consistent low-end torque.
KV Rating: 4300KV tuned for a balance of speed and drivability.
Adjustable Timing: 20-40 degrees lets you dial in response to surface grip.
Compact Build: 36mm diameter and 52.5mm length suitable for standard 1/10 layouts.

Specifications

Type: Brushless, Sensored
Pole Count: 4
LiPo Cells: 2S
No-load Current: 4.2A
Resistance: 5.2mΩ
Shaft Diameter: 3.175mm
Weight: 187g

Well suited to drivers seeking consistent throttle and easy tuning across different track surfaces.

How difficult is installation on a standard 1/10 car?

Installation is straightforward for most 1/10 chassis thanks to the common dimensions and 3.175mm shaft, though minor mount or pinion alignment may be required.

Can I run this motor on brushless or sensored ESCs?

To exploit sensored startup and smooth low-speed control, use a sensored ESC rated for your battery and expected current loads.

What maintenance should I plan for?

Check bearings and cooling after racing sessions, keep gearing clean and ensure the motor runs within safe temperature ranges to prolong life.
