The OS49404160 is a replacement head gasket suited to O.S. Engine GF40 series glow units. It provides the O-ring style seal between the cylinder head and crankcase to keep combustion pressure consistent during operation.
Use this gasket as the direct replacement part when performing scheduled servicing or rebuilding a GF40 engine. Fitting a new gasket any time the head is removed will restore sealing performance and limit compression loss.
Installation notes: remove old gasket residue and degrease mating surfaces, position the gasket using locating features or dowels, and tighten the head screws progressively in a criss-cross order to avoid distortion. Inspect surfaces for flatness and avoid excessive torque.
Maintenance and tuning: keeping a new, properly seated gasket in place ensures steady compression, which makes carburetor and ignition adjustments more repeatable; swap the gasket if you find warping, tears, or fuel contamination.
